This Garage was built recently for a customer in Ballochmyle.
BASE:- The base is a steel reinforced concrete base with a built in damp proof membrane. The base was carefully built to exactly the right size for the new garage helping to ensure a watertight junction between the walls and the base.
WALLS:- The walls are built using our precast concrete panel system manufactured with exactly the same finish as was used on the house walls.
ROOF:- This is tiled using the same “Redland” roof tiles used on the house and white uPVC fascia to match the house. The front and rear gables are finished in Golden Oak uPVC weatherboarding to match the windows on the house. Even the gutters and downpipes exactly match the ones on the house
DOOR:- The main door is an electrically operated high security sectional door finished in Golden Oak to match the doors of the house. The personal door is a uPVC door to match the house.
DRIVEWAY:- We extended the driveway to match the existing and built in a linear drain connected to the existing system
If you feel you need a carefully designed garage to match your house without the cost and delays that go with getting one traditionally built please contact us.
On his job our customer found that the two doors on his garage were too narrow for his car. The solution was as follows:
This job needed a building warrant so we got our structural engineer to produce a design and obtain the necessary building warrant approval from the local authority.
The original doors were removed and the roof and door beams were carefully propped inside the garage all as detailed by the structural engineer.
We were then able to remove the middle column following this we removed the beams and brickwork above the doors. The floor was then reinstated.
The opening was prepared and the new galvanized steel structural beam (from Birtley Beams) was carefully installed and built in place.
Once the beam was ready we rebuilt the facing brickwork above the beam and reinstated the roof soffit.
Approximately a week after fitting the beam we then very carefully removed the roof props
This allowed us to supply and fit the new door. This is a white Hormann electrically operated Georgian style door with vision windows. The door is 16’0” wide by 7’0” high and gives ample room for two cars to park inside the garage.
After completion of the work we obtained a completion certificate for the work from he local authority.
This is a CLASSIC Sectional Tiled Roof Concrete Garage 21’4” long by 10’0” wide (6.50m by 3.05m) with a tiled roof to match the house, two uPVC windows, a Hormann personal door, a Hormann up and over door and low maintenance uPVC fascias.
It took just less than two days to build the tiled roof concrete garage on the pre-prepared brick and concrete base.
First the team carry in and build the wall panels for the concrete garage. These panels are tongued and grooved for added strength and watertightness. The personal door and windows are fitted as they go.
Next one man seals the concrete garage wall joints externally with mastic and sprinkles on matching roughcast chips. At the same time the other two members of the team get on with fitting the timber wall plate around the top of the wall panels.
Following on from this the timber roof trusses are fitted to the wall plates and timber roof bracing is fitted. This is a traditional type of roof construction used on tiled roof concrete garages due to the weight of the concrete tiles.
The gable end roof trusses are fitted with low maintenance uPVC cladding already in place. At the same time another member of the team prepares the roof felt.
After fitting the up and over door and uPVC side fascias and gutters to the concrete garage we then carry on and fit the under tile felt and the tile battens.
This is followed by the tiles which are Marley concrete tiles to exactly match the house.
Finally whilst one of the team puts the finishing touches to the roof the other members are cleaning and tidying the site and checking the Classic Tiled Roof Concrete Garage to make sure it is perfect for handover to our customer.
SUPERVISION: The site was visited on no less than four occasions during the construction of the concrete garage by one of the management team to make sure every thing was progressing to plan and to the complete satisfaction of the customer.
This project is a new garage in Giffnock. The site slopes quite a bit from front to back so rather than lay a concrete base slab we have built brickwork retaining walls around the perimeter on concrete strip foundations at a depth of about 60cm (2’0”) below ground level. The walls have been backfilled with compacted type 1 hardcore and we have laid out the damp-proof membrane. We have also laid out polythene to protect the driveway.
We carefully lay in place the steel mesh reinforcement.
The base is almost ready for the concrete to arrive and we are busy now laying out timbers around the top of the base to make sure the concrete level is about 2.5cm (1”) above the level of the brick perimeter. This, along with the fact that the brickwork is built to the exact size of the garage, minimizes the possibility of water entry at floor level.
A screed board is cut and laid out ready for the concrete to arrive.
Whilst we are waiting for the concrete to arrive we can get on with working on the new fence. There is never an idle moment!
The concrete arrives and on this job it is brought down the driveway in a small dumper as the driveway is quite long. As you can see the driveway is well protected with polythene and boards. The concrete goes in and is leveled out and compacted with the screed board. The concrete we used on this job is a high strength 35newton mix with a special additive to give long term protection against frost.
The concrete delivery driver gets his delivery note signed.
We can now form the small sloping concrete ramp down to the driveway and start to polish the concrete finish around the perimeter of the base. Also time for a short break for lunch.
Accessing the base using a plank across the width we can now polish the middle part of the base.
Whilst one of the men finishes polishing the base the others are removing the protection from the driveway and finishing off the small sloping ramp at the front of the garage.
The base is now complete, however there may be cold weather or rain to come overnight so we need to protect the base. Here we put timbers around the perimeter followed by Heras fence panels, polythene, insulation, more polythene and weigh it all down with planks and blocks. By tomorrow the base will have set and cured to the point where we can remove the covers. The base will be ready for us to build the new garage after about a week.
We are pleased to announce the introduction of a new service to our range. We now offer a choice of GARAGE MAINTENANCE AND SERVICE PACKAGES. They will give you peace of mind that you have met the annual servicing and maintenance requirements of any garage doors that are still under warranty. Depending on the package you select it may also give you the peace of mind that you can satisfy your buildings insurance company that you have taken reasonable measures to check over your garage roof and doors. All of this without the burden of having to carry out the annual servicing and maintenance of your Roof/Door/Garage yourself. As always all of our work is carried out by our own in house, fully trained service team.
To go ahead simply contact us to let us know which of the options below you would prefer.
OPTION A: GARAGE ROOF – £80
Remove debris from roof sheeting*, gutters & downpipes. Clean roof sheets*, fascias and flashings. Ensure all fixings are tight sealed and capped.
OPTION B: GARAGE DOORS – £80
Wash inside and outside and carry out a full annual service as recommended by Hormann.
OPTION C: GARAGE ROOF AND DOORS TOGETHER – £140
As options A & B combined and carried out in one visit.
FULL GARAGE SERVICE – £170
As options A & B combined and carried out in one visit.
Full service as A and B for your Welsh Concrete Garage. plus: Remove minor build up of debris around garage walls, ensure all seals are in place between joints and tighten bolts as necessary. Inspect and maintain cement seals as required. Service side door as required. Clean windows etc.
*This service is for sheeted roofs. If you have a tiled roof let us know and we can work out an accurate fixed price quotation.
Most people take garage doors for granted, but maintaining your garage door to the right specification will keep your garage door young and fit. The most common type of doors are Canopy and retractable up and over doors. Canopy doors have a slight overhang at the front of the garage ie if you are standing at the front of the garage in the rain you won’t get wet. Retractable doors are designed to go fully inside of the garage when open. These are excellent when automated.
All garage doors need some tender loving care at least once a year a bit like us. Firstly, visually inspect the general condition of the door, all components, and safety devices for completeness, proper condition and effectiveness. Then check that all the fixing points are tight. Tighten the screws if necessary. The mechanism of the door also needs some care. All the pivot points of the garage door need lubricated with a standard penetrating or lube oil. Do not use grease! On canopy doors you should inspect the cables for wear and tear.
The steel surfaces of the garage door needs cleaned with soapy water and a soft sponge at least every 6 months unless you live in a coastal area then this should be every month. If the door is more heavily soiled please use a mild, acrylic-compatible plastics cleaner. Your door also needs protection from caustic and aggressive substances for example nitrous reactions from stones or mortar, acids, de -icing salts and aggressive paints or sealants.
Our Maintenance Service
In fact, why not save yourself all this hassle and get in touch with D Welsh Builders about maintaining your garage door on a yearly basis! Our expert Door Fitters are experienced in giving your door the specialist tender loving care it requires!
